Description
HCFS207-21 bearing is a 1-5/16″ bore four-bolt normal-duty flange bearing that utilizes an eccentric locking device to secure to a 1-5/16″ shaft. HCFS207-21 flange bearings are designed for circumstances where the bearing is mounted to a surface perpendicular to the shaft axis and poses great stability and rigidity due to the four mounting positions. Our superior HCFS207-21 bearing with a 1-5/16″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our HCFS207-21 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, and relubricating capabilities. HCFS207-21 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our HCFS207-21 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our HCFS207-21 bearings, and we will be happy to assist you!
HCFS207-21 Bearing Dimensions
- Part #: HCFS 207-21
- Shaft Diameter (d): 1-5/16″
- Dimension (A): 4.56″
- Dimension (E): 3.625″
- Dimension (I): 0.83″
- Dimension (G): 1.38″
- Dimension (L): 0.51″
- Dimension (S): 2.09″
- Dimension (Z): 2.0118″
- Dimension (Bi): 0.7402″
- Dimension (N): 0.7402″
- Dimension (M): 1/2″
- Bolt Used: 1/2
- Dynamic Load Rating (LBS): 5.775
- Static Load Rating (LBS): 3.497
- Bearing Insert: HC 207-21
- Housing Number: FS 207
- Weight (LBS): 3.5
