Description
XTB100 bushing with 9-1/2″ bore is a precision-manufactured bushing made for XT type hubs. XTB100 bushings are utilized in a variety of applications such as belt pulleys, sprockets, and drums. Because our XTB100 bushings are manufactured from high-quality materials, the installation process and removal process is easy. For more information or to get a quote on XTB100 bushings with a 9-1/2″ bore, contact our customer service team, and we will be happy to assist you.
XTB100 Bushing With 9-1/2″ Bore Dimensions
- Bushing Size: XTB100
- Bore Size: 9-1/2″
- Dimension (A): 1-9/16″
- Dimension (B): 13.688″
- Dimension (D): 17-15/16″
- Dimension (L): 6-3/16″
- Dimension (BC): 15-9/16″
- Bolt #: 6
- Size: 1-1/8″ – 7NC X 4
- Recommended Wrench Torque (ft.-lbs.): 750
- Weight: 146 LBS
