Description
UCHA206-19 bearing is a 1-3/16″ bore normal-duty hanger bearing that utilizes set screws to secure to a 1-3/16″ shaft. UCHA206-19 hanger bearings are designed for applications such as screw conveyors and suspended shafts. Our superior UCHA206-19 bearing with a 1-3/16″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid cast-iron housing. Additionally, our UCHA206-19 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, relubricating capabilities, and strategically placed set screws. Our UCHA206-19 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our UCHA206-19 bearings, and we will be happy to assist you!
UCHA206-19 Hanger Bearing Dimensions
- Part #: UCHA206-19
- Shaft Diameter (d): 1-3/16″
- Dimension (A): 3.07″
- Dimension (W): 4.06″
- Dimension (C): 0.00″
- Dimension (H): 2.52″
- Dimension (L): 1.57″
- Dimension (D): 0.75″
- Dimension (K): PF 3/4
- Dimension (Bi): 1.5000″
- Dimension (N): 0.6260″
- Dimension (M): 0.8740″
- Dynamic Load Rating (LBS): 4,377
- Static Load Rating (LBS): 2,569
- Bearing Insert: UC 206-19
- Housing Number: HA 206
- Weight (LBS): 1.9
