Description
SAF 520 housings are designed for some extreme industrial applications; this housing is a split pillow block housing made from cast iron for spherical roller bearings. The split design of a SAF520 housing allows for easy mounting and maintenance, while the heavy-duty construction permits this bearing to operate in higher-load applications compared to other types. Our SAF520 bearing is cast from a high-grade cast and is designed with a reinforced webbed base for better heat distribution and prevention of over-tightening. Additionally, the housing features two threaded plugged holes on top for a grease fitting and various testing equipment, while the bottom faces of the housing have a drain plug on each side. SAF520 housings are commonly found in applications such as; steel mills, queries, and large drive or conveying applications. For additional information or to get a quote on our SAF 520 housing, contact our customer support team, and we will be happy to assist you!
SAF 520 Housing Dimensions
- Housing #: SAF520
- Dimension (D): 180mm
- Dimension (a): 15″
- Dimension (b): 4-3/8″
- Dimension (c): 1-3/4″
- Dimension (h): 4-1/2″
- Dimension (W): 8-3/4″
- Dimension (M – max.): 13-1/8″
- Dimension (M – min.): 11-5/8″
- Dimension (n): -“
- Dimension (S): 7/8″
- Cap Bolt Size: 5/8-11
- Style: 1
- Labyrinth Seal Ring: LER102
- Stabilizing Ring: SR20-17
- Weight (LBS): 49.60
