Description
HCST205-14 bearing is a 7/8″ bore normal-duty take-up bearing that utilizes an eccentric locking collar to secure to a 7/8″ shaft. HCST205-14 take-up bearings are designed for take-up frames, which creates an assembly that maintains and adjusts tension for conveyor and drive systems. Our superior HCST205-14 bearing with a 7/8″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid cast-iron housing. Additionally, our HCST205-14 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, and relubricating capabilities. Our HCST205-14 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our HCST205-14 bearings, and we will be happy to assist you!
HCST205-14 Take-Up Bearing Dimensions
- Part #: HCST205-14
- Shaft Diameter (d): 7/8″
- Dimension (O): 0.63″
- Dimension (G): 0.39″
- Dimension (P): 2.00″
- Dimension (Q): 1.25″
- Dimension (S): 0.75″
- Dimension (B): 2.00″
- Dimension (K): 0.53″
- Dimension (E): 3.00″
- Dimension (A): 3.50″
- Dimension (W): 3.84″
- Dimension (J): 1.25″
- Dimension (L): 0.94″
- Dimension (H): 2.44″
- Dimension (Bi): 1.7480″
- Dimension (N): 0.6850″
- Dimension (M): 0.6890″
- Dynamic Load Rating (LBS): 3,155
- Static Load Rating (LBS): 1,810
- Bearing Insert: HC 205-14
- Housing Number: ST 205
- Weight (LBS): 2.0
