Description
This 103C49 sprocket is a 49 tooth cast construction sprocket with a C-Hub (hub on both sides). This sprocket is in the 103 series of engineer class sprockets. It can be supplied with a stock plain bore, finished bore with key-way and set screws, or as an idler sprocket configuration. This sprocket works with chain sizes 103, SBO2103, C9103, WH9103HD, SCA9103, C131, ER131, SBS131, and WH82.
103C49 Dimensions
- Tooth Count: 49
- Style: C
- Pitch Diameter: 48.00″
- Hub Diameter: 10.00″
- Length Thru Bore: 6.00″
- Max Bore: 8.00″
- Tooth Face at Pitch Line: 1.125″
- Roller Diameter: 1.218″
- Weight: 301.0 LBS
USA Roller Chain and Sprockets always strives to provide the industry leading service we are known for, as well as competitive and fair prices. Besides sprockets we also offer a full line of roller and engineer class chains, motors with gear reducers, v-belts, pulleys, and a wide variety of other industrial power transmission products. For more information or to get a quote on 103C49 sprockets or any other products, please contact our customer support team and we will be happy to assist you.
